Largest discount 5kva-1000KVA electric power generator diesel engine super silent diesel generator set price
diesel generator
Support us
Support us, send inquiry to us NOW.
CSCPOWER is professional genset supplier, we are located in fuzhou, Fujian Province, China.
We supply all kinds of diesel generator, from 5kva up to 2000kva.
engine brand for option: with cummins engine,UK engine, deutz, weichai, weifang,yandong, xichai, etc
Alternator band for option: stamford, leory somer, cscpower copy stamford, STC, etc.
Controller: deapsea 6020,7320,8610, comap AMF20, smartgen 420,6110,6120, etc
Genset type: open, silent, trailer, light tower,Paralleling system, etc
Certificates: CE, ISO, SONACAP, SASO, CIQ, OEM of with cummins engine, deutz, leory somer, stamford, etc
CSCPOWER is reliable company, CSCPOWER credit has been checked by ALIBABA financial. CSCPOWER has passed a financail assessment(including a credit check) conducted by ALIBABA financial, including People's Bank of China credit archives, business data, Alibaba network behavioral data, corporate and personal balance sheet, court enforcement records.
Largest discount 5kva-1000KVA diesel generator Three phase and one phase
CSCPOWER 10kva -1000KVA Production lineiesel ge10-nrator disel generator
5KVA Noise leve at 7m is only 62DB(Best in China)
ies
Light tower production line
e
netor
Trailer genset production line
5-10KVA Small diesel generator techncial specifications
| Specification | |||||||||||||||
| Gen-set Model | DG3500SE | DG6700SE | DG6700SE-3 | DG7500SE | DG7500SE-3 | DG12000SE | DG12000SE-3 | ||||||||
| Alternator Type | Brush, Single phase, alternator | Brush, 3-phase | Brush,Single phase | Brush, 3-phase | Brush, Single phase | Brush, 3-phase | |||||||||
| Frequency (Hz) | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | |
| Max. AC output (KVA) | 3.0 | 3.3 | 5.0 | 5.2 | 4.6 | 4.8 | 5.6 | 6 | 6 | 7 | 11 | 12 | 12 | 13 | |
| Cont. AC output (KVA) | 2.8 | 3.0 | 4.8 | 5.0 | 4.4 | 4.6 | 5.4 | 5.5 | 6.2 | 6.6 | 10 | 11 | 11 | 12 | |
| Power factor(cos) | 1.0 | 1.0 | 0.8 | 1 | 0.8 | 1 | 0.8 | ||||||||
| Voltage (V) | 110,120,220,230,240,110/220,120/240 | 220/380, 230/400 | 220, 230,240 | 220/380, 230/400 | 220, 230,240 | 220/380, 230/400 | |||||||||
| DC output (V/A) | 12/8.3 | ||||||||||||||
| Insulation Class | B | F | |||||||||||||
| Engine | Engine Model | DE178FAG3(E) | DE186FAG3(E) | DE186FAG3(E) | DE188FAG3(E) | DE188FAG3(E) | DE2V840 | DE2V840 | |||||||
| Engine Type | Single-cylinder, 4-stroke, air-cooled diesel engine | V-twin cylinder,4-stroke,air-cooled diesel engine | |||||||||||||
| Combustion System | Direct injection | ||||||||||||||
| Bore x Stroke (mm) | 78 x 64 | 86 x 72 | 86 x 72 | 88 x 72 | 88 x 72 | 2-86 x 72 | 2-86 x 72 | ||||||||
| Displacement (cc) | 306 | 418 | 418 | 438 | 438 | 836 | 836 | ||||||||
| Engine Speed (rpm) | 3000 | 3600 | 3000 | 3600 | 3000 | 3600 | 3000 | 3600 | 3000 | 3600 | 3000 | 3600 | 3000 | 3600 | |
| Starting System | Open type: Recoil start/Electrical start, Silent type: Electric start | ||||||||||||||
| Fuel Tank Capacity (L) | 16 | 21 | |||||||||||||
| Lubrication Oil Volume (L) | 1.1 | 1.65 | 1.65 | 1.65 | 1.65 | 1.7 | 1.7 | 1.7 | 1.7 | ||||||
| Fuel Type | 0# (Summer), -10#,-20# (Winter) light diesel oil | ||||||||||||||
| Lubrication Oil Type | SAE 10W/30 | SAE 10W/30(CD grade above) | |||||||||||||
| Low Oil Pressure Alarm System | With | ||||||||||||||
| Lubrication System | Forced lubrication via trochoids pump | Forced & splashing | |||||||||||||
| Cooling System | Forced-air cooling | ||||||||||||||
| Noise level | 65-70DB at 7m | 72-75DB at 7m | |||||||||||||
| Gen-set | Continuous running hours (hr) | 10.8 | 9.6 | 7.3 | 6.2 | 7.3 | 6.2 | 7 | 6 | 7 | 6 | 6 | 5.3 | 6 | 5.3 |
| Gross Weight (kg) | 155 | 170 | 170 | 170 | 170 | 245 | 245 | 245 | 245 | ||||||
| DIM (L x M x H) (mm) | 880 x 570 x 760 | 960 x 570 x 760 | 960 x 570 x 760 | 960 x 570 x 760 | 960 x 570 x 760 | 1140 x 750 x 785 | 1140 x 750 x 785 | ||||||||
| Packing in 20ft and 40HQ container | 72sets | 150sets | 72sets | 150sets | 72sets | 150sets | 72sets | 150sets | 72sets | 150sets | 63sets | 126sets | 63sets | 126sets | |
20KVA-1000KVA Diesel generator technical specifications
CSCPOWER Super Silent genset advantages:
diesel generator diesel generator
CSCPOWER LATEST EXHIBITION NEWS
WELCOME TO VISIT OUR EXHIBITION IN TANZANIA AND SOUTH AFRICA i
diesel gen
erator
diesel generato
diesel generator
FAQ Of DS-2F diesel generators prices
diesel generator
1.Which parameters you need to know? a.We design the product according to your request, such as: Power, Working Life, Water/Air-Cooler, Open Frame , Silent and Wheel |
2.How to deal with broken machine? a.We provide professional technical response to your question, we make Sure the configuration, feature, optional item can work.
Maintenance Return your parts to us (Freight by yourself) b. Enclose more parts when shipment Parts Reply to you as quickly as possible |
3. What do we warranty? One year quality warranty. Offer 24 hours service on telephone helpline. Whichever comes first. a.During guarantee period, we provide free quick-wear parts for problem caused by our quality of production or raw material. b.After expiration, we provide spare parts maintenance for half price. |
4.What about Guarantee? a.Good reputation for reliable quality and reasonable price b.Advanced production line by skilled workers c.Two hours strictly testing of the machine before shipment d.CE ISO BV |
